100T Box Pan Brakes Bending Press Machine For Sale

Box pan brakes bending press machine has high labor productivity and high working accuracy for bending metal sheets.

Box Pan Brakes. It adopts different shapes of upper and lower molds and can be bent into various shapes of workpieces.

Box Pan Brakes. Hydraulic Press Brake Bending Machine can bend sheet once by one stroke of the slider. , After many times of bending, the workpiece with a more complicated shape can be obtained.

When equipped with corresponding equipment, Hydraulic Press Brake Bending Machine can also be used for punching.

Working slide structure

1. Box Pan Brakes. The machine adopts hydraulic and electrical control, the stroke of the slider can adjust arbitrarily and has the action specifications of inching, semi-automatic, automatic, etc., and the inching specification can use for easy mold trial and adjustment.

2. Box Pan Brakes. The design of the upper-moving bending machine, the two cylinders work at the same time, the operation balance, convenient and safe.

3. Box Pan Brakes. There is a pressure-holding delay function at the bottom dead center to ensure the accuracy of the workpiece. press brake machine.

4. Under the relevant national standard conditions, the bending angle accuracy can reach ±45´. (Quoted standard JB/T22572-2011).

5. With the function of slow descent control, the operator can better control the workpiece.

Features of hydraulic press brake

1 The whole welded machine structure achieves high rigidity; the machine is designed by ANSYS software which can ensure the reliability and precision of the press brake.

2 The motors for the back gauge and ram stroke are controlled by an inverter, which can achieve a high positioning accuracy of the back gauge and ram by changing the frequency and voltage of the motor.

3 Different punch and dies are optional according to the customer’s requirements, such as Multi-V die, radius die, gooseneck dies, etc. One set of complete standard punch and die will be included for free.

4 X-axis(Backgauge) and Y-axis(Ram stroke or cylinder stroke) can be programmed by the E21 system controller, which can store up to 40 groups of programs.

5 Hydraulic overload can be protected by an overflow valve, System pressure can be regulated by a pressure switch easily.

6 Footswitch with an emergency button can stop the machine immediately when an accident happens. Hydraulic press brake

After Sales Service for CNC Torsion Bar press brake

1.Warranty period is 12 months after receiving machine; any quick-wear part is available for free during guarantee period under proper operation, customers only need to pay for the freight of the replaced new parts.

2.Installation and training service is optional for customers, any client can ask for this service from HARSLE, they should assume the airfare and accommodation for our engineer during the journey.

Company information

HARSLE is a leading and professional metalworking machine manufacture in china, which was established in 1997 and located in the culture ancient city of Nanjing, Jiangsu province. After 20 years corporations; are Nanjing HARSLE CNC Machine Tool Co., Ltd, and HARSLE INDUSTRIAL LIMITED.

Its sales revenue has been increasing by over 100% yearly in recent years.
HARSLE endeavors to provide high-quality machines and satisfied after-sales service, our machine products including NC&CNC PRESS BRAKE.

Swing beam shearing machine, guillotine shearing machine, mechanical & pneumatic machine, hydraulic press machine, rolling machine, ironworker, laser cutting machine, and steel door production line, etc. They have been sold to over 100 countries and 10000 customers all over the world in different fields.
