4×2500 Metal Shear Machine With E200PS For Sale

Metal shear machine not only provides high strength and sensitivity but also lower your production cost and improve your bottom line. And superior design allows for our power shear machine to offer smooth, precise cuts whether you are cutting thin or thick material.

Main features of QC12K cutting machine

1 4×2500 Metal Shear Machine. The streamlined welded machine structure achieves high rigidity; the machine is designed by ANSYS software which can ensure the reliability and precision of the shearing machine.

24×2500 Metal Shear Machine.  The motors for the back gauge are controlled by an inverter, which can achieve a high positioning accuracy of 0.05mm of the back gauge by changing the frequency and voltage of the motor. QC12K cutting machine

3 Top blade with two cutting edges and bottom blade with four cutting edges (6CrW2Si).

4 X-axis(Backgauge) and cutting time can be programmed by the E21S system controller, which can store up to 40 groups of programs.

5 Pressing foot can fix the metal sheet during cutting operation which can eliminate operator error.

6 Hydraulic overload can be protected by overflow valve, knife rack returns by Nitrogen cylinders.

7 Footswitch with an emergency button can stop the machine immediately when an accident happens.

8 Adjusting the knife gap between upper and bottom blades can achieve better cutting performance.

9 Front arms with ruler and roll balls can ensure cutting accuracy and feed the material easily.

After Sales Service for QC12K cutting machine
1. Warranty period is 12 months after receiving machine; any quick-wear part is available for free during guarantee period under proper operation, customers only need to pay for the freight of the replaced new parts.
2. Installation and training service is optional for customers, any client can ask for this service from HARSLE, they should assume the airfare and accommodation for our engineer during the journey.
